High-speed slip rings are a type of rotary joint typically used in equipment with rotational speeds exceeding 1000 revolutions per minute, especially in small to medium-sized products. Due to the high-speed rotational nature, conventional off-the-shelf slip ring designs are inadequate, necessitating specialized custom solutions. JINPAT, as an established international slip ring manufacturer, boasts remarkable technical expertise in this field, offering a range of high-speed custom slip ring products to the market.
Within the capsule slip ring family, JINPAT has introduced the YS series, which includes products with a 1000 RPM rotational speed. These products are meticulously designed to meet therequirements of high-speed rotation, providing reliable power and signal transmission for various small to medium-sized devices. Moreover, small to medium-sized slip rings are not limited to capsule products, as JINPAT has made significant technological advancements in the field of hollow shaft series high-speed custom slip rings, developing through-hole slip rings with a maximum aperture of 80mm and a maximum speed of 10,000 RPM.
JINPAT delivers brand new capsule or hollow shaft series high-speed slip ring products each month. For instance, the LPT000-04S-01FO is a recent high-speed hollow shaft slip ring with a maximum designed speed of 3000 RPM. This product is primarily used for signal transmission, including 4 channels of DC signal paths and optical signal paths.In terms of size, it is very compact, with an electrical slip ring height of 44mm, plus a rotor height of 6.5mm, resulting in a total height of only 50.5mm.
Another new high-speed hollow shaft slip ring is the LPT000-30S, also a product focused on signal transmission,integrating 30 signal paths. Although slightly larger, its design still complies with high-speed slip ring standards, with a diameter of 63.5mm and a height of 105.8mm. Additionally, JINPAT has introduced the LPT012-1605-HS, a through-hole slip ring with a maximum speed of 4000 RPM, primarily designed for electrical slip rings but also supporting mixed transmission of signals and currents when needed.
JINPAT has recently introduced numerous customized models in the YS series of high-speed capsule slip rings, such as LPM-04YS-0402, LPM-12YS-0501, LPM-12YS-0502-01S, LPC-15YS-1202,LPC-24YS-0602-18S, and LPC-24YS-18S, to name a few. These products have the same design speed as the standard YS series capsule products, which is 1000RPM. These products encompass not only regular electrical slip rings but also slip rings that integrate power and signal transmission functionalities to meet specific customer demands.
In conclusion, JINPAT high-speed custom slip rings offer reliable solutions for various high-speed rotation applications. Regardless of your specific requirements, you can rely on our rich experience and exceptional technology in the field of high-speed slip rings to meet your needs.
